Source / Attribution:

These are remixed from https://www.thingiverse.com/thing:2860289.  I wanted to clean up the F3D file so I could follow it and create some additional mounts.  Having done that, it makes sense to release my updates back to the community.  I've printed a few of these, and they fit well.

Included Files:

I've included the F3D file and the STLs.  They should be oriented in printable position.  There's also a 3mf file that gives suggested print and support settings in PrusaSlicer.  While it shows a couple mounts, the suggestions should work for all of them.

Note: The “v” suffixes are from the Fusion 360 file version, not the Dyson vacuum version!

Print Settings:

• PLA works, PETG would be fine
• 2-4 perimeters, recommend at least 3 for the “Extra Wide” form factor.
• 15% infill, grid or gyroid
• 0.2mm layer height (untested at 0.3mm, but may work)
• .55mm external perimeter width
• .5mm internal perimeter width
• No gap fill
• PrusaSlicer snug supports
  • The notches in the receiving sections do not need supports

Compatible Dyson Models:

• v7
• v8
• v10
• v11
• v15
• Gen5 Detect vacuum wall mount
