NEW Added 200mm clip arm for larger bags.

Updated: 08/16/2024 - added an extended angled version of the insert to accommodate low cabinet clearance. @Leon61 thanks for the suggestion

Updated: 04/07/2024 - added an extended version of the insert to help the cap clear the coffee bag.

Updated: 5/17/2023 - Cap is pre-scaled up to 104%.

Shout out to Minkix for the original design(https://www.thingiverse.com/thing:4744855). I had made some design changes to remedy issues encountered. Nonetheless, great concept by Minkix!!

1. Sealing grooves edges were too sharp and cutting into the bag breaking the air seal.
   a. A single rounded sealing groove used instead
2. Insert free-spins
   b. A notch is added to prevent insert from free-spinning

Note: Though coffee bean/ground contact is minimal, using food grade filament for the insert is still recommended.

Notes:

Insert printed at 0.1mm layer height, 15% infill, 3 lines perimeter with 5 lines of brim

Cap printed at 0.1mm layer height, 15% infill, 3 lines perimeter

Arms printed at 0.2mm, 15% infill, 3 lines perimeter
